Single/Lean To Carport 3.0 x 5.0m

Product number
DE2289
Suitable for sheltering one vehicle
Lean-to or freestanding structure
Treated wooden frame and transparent PVC roof panels
carport_enkelaanbouw_sfeer
carport_enkel_plattegrond
Per piece,from

1,087.66

incl. vat

23 pieces in stock
2 to 3 weeks
Details
Depth
500 cm
Width
300 cm
Height
260 cm
  • Rated on Trustpilot with an 4.3/5
  • Unbeatable Industry Knowledge
  • Fast delivery in the UK
Post Holders
1,087.66incl. vat
2 to 3 weeks
  • Rated on Trustpilot with an 4.3/5
  • Unbeatable Industry Knowledge
  • Fast delivery in the UK

Pros and cons

  • comfortably houses your motorbike or car

  • Boiler pressure-impregnated pine wood for a long service life

  • Also suitable as an extension carport

  • Exclusive of foundations (such as post holders or concrete posts)

Specifications

Material
Wood
Wood type
Softwood
Colour
Green
Width
300 cm
Depth
500 cm
Height
260 cm

Single/Lean To Carport 3.0 x 5.0m

This single flat roof carport can be used as a lean-to or freestanding structure, allowing for use within a wide range of outdoor spaces. An economical alternative to a garage, this carport offers an effective way to protect one vehicle from the elements.

Featuring a pressure treated wooden frame, this is combined with transparent PVC corrugated roof panels to provide the sheltered element. The only difference between the freestanding and lean-to designs is the number of supporting posts - to convert into the lean-to, use three of the six posts supplied as standard.

The posts are to be dug in at a depth of 60cm, or when mounted with post holders, to be shorted to a height of 2.30m. If required, the clearance height can be increased using post points.

To use as a lean to carport longer roof sheets will need to be sourced locally. A discount will be applied if not supplied.

The Single/Lean To Carport features:

  • Pressure treated timber

  • Transparent PVC corrugated roof panels supplied with screws with EPDM washers

  • Fixings

Dimensions:

  • Width: 3.0m

  • Depth: 5.0m

  • Height: 2.60m

  • Head-room: 2.30m approx.

  • Posts: 8.8 x 8.8cm

  • Post Height: 2.90m

  • Snow Load Max: 100kg p/m2

Ground Anchors For Gazebos:

  • Screw down Post Holders - An above ground fixing method, requires a hard standing such as concrete, slabs or a timber frame.

  • Spiked Post Holders - A below ground fixing option, intended to be hammered into soft ground.

  • Adjustable Ground Anchors - A below ground anchor which needs to be concreted into place.


Please note that there are no bolts/fixings with these post holders - They will need to be sourced separately.

This is an adaptable car port, if needed the post can be brought in closer from the outside, the rafters can also be cut shorted upon installation if a smaller size is required.
