Double glazing in log cabins

When asked for double glazing in 28mm log cabins, I tell customers that “there is no point to it”. “The walls are not thick enough to warrant it or the extra expense for it”

This post helps to explain more about why I say this.

Before I get onto the double glazing first of all have a look at this:

This is very self explanatory. 25% lost through the roof, another 10% through the floor. So before we worry about the glass, lets get that 35% sorted.

Have a look at my recommendations for insulating of a log cabin roof and floor. That will take care of 35% of our worries. Please keep in mind that 50mm of Celotex or similar has a R value of 2.25 and a U value of 0.44 – we’ll come back to this.

We can also, quite easily, remove another 15% caused by drafts. All our cabins appear extremely tightly, sometimes too tightly. The moisture content is 14 – 16% in our log cabins and we use proper corner connections, drafts are kept to a minimum. Sure sometimes a fitter will add extra trims, sometimes you might want to add a little more to the building. Drafts though we can easily stop.

So, that’s taken care of 50% of the worry of heat loss; Insulate the roof and floor and keep the drafts down!

Log Cabin Walls

Now let’s look at another big chunk, a whopping 35% of the building – the walls!

You will have seen from the range that there is something for everyone, we offer lots of different styles with varying log thicknesses and this is borne from experience of the uses and requirements for each thickness. It stands to reason that a thinner log has less thermal efficiency than a thicker one, so lets look at our most popular sizes: 28mm , 45mm and 58mm.

R values and U values

This is where it gets a bit heavy but bare with it.

R Value: This is a measurement of the resistance of the flow of heat through a given thickness. This is mainly for a solid material such as a lump of wood, in this case Spruce. Once finding the R value, we can convert it to a U value. Higher the R value the better!

U Value: This is a measurement of heat loss in watts when the outside temperature is at least one degree lower. It is often made up of the sum of parts such as double glazing (glass and air) Lower the U value the better!

Spruce log cabin logs - R values and U values

I did a lot of research on this recently. Some people give some wild figures, one UK supplier I found was giving mad and very misleading figures. I have though tried to be quite impartial with this. The lowest figure for Spruce is the American R value of 1.41 / inch with a 0.1 / inch increase due to the thermal mass of the timber. I have then applied a European conversion from US R Value to the European R value (multiply by 0.1761)

By my very low and conservative calculations the three popular sizes of dried Spruce Log came out as:

• 28mm Spruce Logs – R Value 0.29 – U Value 3.42

• 45mm Spruce Logs – R Value 0.45 – U Value 2.21

• 58mm Spruce Logs – R Value 0.61 – U Value 1.64 An 18mm Spruce roof board is – R Value 0.19 – U Value 5.16

As a point of reference:

• 1976 the U value for a house wall was 1.7.

• In 1985 it lowered to 1.0.

• 1990 reduced to 0.6

• 2002 reduced to 0.35.

You can see from this that a log cabin in these wall thicknesses is never going to be as good as your house, not without extra lining at least. Though you can also see how much more heat we lose through a 28mm thick log cabin, and the roof loss is just huge on any log cabin if you’re leaving just the roof boards.

This is where you need to decide on what the you will use log cabin for? A leisure building, summer house, a shed / storage type of cabin is perfect as 28mm. For an office or accommodation 58mm or above is a must. 45mm log cabins are the middle ground and you will need to make some trade offs. Of course you could also go thicker, 70mm – 90mm ,120mm and so on but there is always trade offs between the product cost and heat savings.

Of course if heat retention is a big concern any of the buildings can be lined and then further insulated if done so correctly, please visit our expansion and contraction page for more details on how to safely achieve this.

A Log Cabin solely on it’s own will never get to these levels, especially 28mm or 19mm not without a LOT of extra work. Maybe save the extra work and look to thicker logs?

Roof and floor - 50% of heat loss

Remember the roof and floor insulation I recommended above gave you a U value of 0.44. If we consider heat loss, at least fit this to your roof and floor, we know that we lose 50% through drafts, the roof and the floor. This area is the MAIN worry before moving on to double glazing your log cabin.

Double glazing in log cabins

So, we’re down to the last 15% of heat loss, the windows and double glazing.

Here are the Values to consider, remember: Higher the R value is better and Lower the U value is better.

• Single pane of glass – R Value 0.94 – U Value 1.10

• Double pane of glass with an air gap – R Value 1.93 – U Value 0.52

Have a look at these figures and compare them with the log cabin figures I gave you earlier:

• 28mm Spruce Logs – R Value 0.29 – U Value 3.42

• 45mm Spruce Logs – R Value 0.45 – U Value 2.21

• 58mm Spruce Logs – R Value 0.61 – U Value 1.64

An 18mm spruce roof board – R Value 0.19 – U Value 5.16 – This can easily be rectified though by adding roof and floor insulation in your log cabin.

It’s interesting to see isn’t it? This is why we don’t offer double glazing with everything. There really is no need for the customers extra expense.

A 28mm log cabin with a U value of 3.42 cannot benefit in any way from double glazing at 0.52 as more heat is going out of the walls than the glass widow, the same can be said for 45mm but it does start to make sense with the 58mm log cabins.
